8-428 Cutting Mandrel
8-469 Motor
8-470 Motor Switch
8-476-1 Chuck Jaw - Left & Right Hand
8-478 Spindle - Tail Stock
8-479 Tie Rod - Front & Rear
8-480 Ball Bushing
8-481 Spacer - Ball Bushing
8-484 Rods - Guide Circular Blade Mounting Block
8-485 Housing - Guide Rod Bushing
8-486 Bushing - Guide Rod
8-487 Mounting Bracket - Scale (vertical)
8-488-1 Mounting Bracket - Scale (horizontal)
8-489 Connecting Link - Blade Lever
8-492 Mounting for Scale Assembly
8-505 Dog Point
8-493 Scale - 6 “
8-621-8 Guard for 126-8 Chuck
8-621-10 Guard for 126-10 Chuck
8-667 Screw - Chuck for 126-10
8-669 Screw - Chuck for 126-8
8-682 Guard - Toggle Switch
8-693 Locking Handle for Tailstock
8-694 Knob
8-695 Pivot - Connecting Link
8-695-1 Pivot - Connecting Lever
8-696 Line Cord
11- 320 Guard Drive
11-321 Plate - Motor Mount
11-322 Plate - Chuck Shaft Bearing
11-323-8 Chuck - 126-8
11-323-10 Chuck - 126-10
11-324 Slide Block
11-325-1 Mounting Block - Circular Blade
11-326-8 Guard - Circular Blade 8”
11-327 Lever - Circular Blade
11-328 Feet-Mounting Bars
11-400-10 Guard - 10” OD Circular Blade
17-164-8 Loading Guard -8” Diameter Blade
17-164-10 Loading Guard - 10” Diameter Blade
LS-1A Bracket - Tailstock
*8-698 Circular Blade - 8”
*8-697 Circular Blade - 10”
8-491 Scale Mount - Adjustable

PARTS NOT PICTURED

Woodruff Key - 1/4 x 7/8
8-428A Bearing Mandrel
8-471 Pulley - Motor
8-472 Pulley - Chuck Shaft
8-473 Belt - Timing
8-474 Bearing - Chuck Shaft
8-475 Shaft - Chuck
8-477 Tie Rod - Drive Area
8-482 Lock Rod - Slide Block
8-490 Chuck Wrench
8-622 Clamp - Circular Blade, Loading GuardWasher for Lever - 3/8 Heavy, Ground to fit
